8 Powerful Awk Built-in Variables – FS, OFS, RS, ORS, NR, NF, FILENAME, FNR

Linux Awk Tutorial - Awk Built-in Variables ExamplesThis article is part of the on-going Awk Tutorial Examples series. Awk has several powerful built-in variables. There are two types of built-in variables in Awk.

  1. Variable which defines values which can be changed such as field separator and record separator.
  2. Variable which can be used for processing and reports such as Number of records, number of fields.

1. Awk FS Example: Input field separator variable.

Awk reads and parses each line from input based on whitespace character by default and set the variables $1,$2 and etc. Awk FS variable is used to set the field separator for each record. Awk FS can be set to any single character or regular expression. You can use input field separator using one of the following two options:

  1. Using -F command line option.
  2. Awk FS can be set like normal variable.
Syntax:

$ awk -F 'FS' 'commands' inputfilename

(or)

$ awk 'BEGIN{FS="FS";}'
  • Awk FS is any single character or regular expression which you want to use as a input field separator.
  • Awk FS can be changed any number of times, it retains its values until it is explicitly changed. If you want to change the field separator, its better to change before you read the line. So that change affects the line what you read.

Here is an awk FS example to read the /etc/passwd file which has “:” as field delimiter.

$ cat etc_passwd.awk
BEGIN{
FS=":";
print "Name\tUserID\tGroupID\tHomeDirectory";
}
{
	print $1"\t"$3"\t"$4"\t"$6;
}
END {
	print NR,"Records Processed";
}
$awk -f etc_passwd.awk /etc/passwd
Name    UserID  GroupID        HomeDirectory
gnats	41	41	/var/lib/gnats
libuuid	100	101	/var/lib/libuuid
syslog	101	102	/home/syslog
hplip	103	7	/var/run/hplip
avahi	105	111	/var/run/avahi-daemon
saned	110	116	/home/saned
pulse	111	117	/var/run/pulse
gdm	112	119	/var/lib/gdm
8 Records Processed

2. Awk OFS Example: Output Field Separator Variable

Awk OFS is an output equivalent of awk FS variable. By default awk OFS is a single space character. Following is an awk OFS example.

$ awk -F':' '{print $3,$4;}' /etc/passwd
41 41
100 101
101 102
103 7
105 111
110 116
111 117
112 119

Concatenator in the print statement “,” concatenates two parameters with a space which is the value of awk OFS by default. So, Awk OFS value will be inserted between fields in the output as shown below.

$ awk -F':' 'BEGIN{OFS="=";} {print $3,$4;}' /etc/passwd
41=41
100=101
101=102
103=7
105=111
110=116
111=117
112=119

3. Awk RS Example: Record Separator variable

Awk RS defines a line. Awk reads line by line by default.

Let us take students marks are stored in a file, each records are separated by double new line, and each fields are separated by a new line character.

$cat student.txt
Jones
2143
78
84
77

Gondrol
2321
56
58
45

RinRao
2122
38
37
65

Edwin
2537
78
67
45

Dayan
2415
30
47
20

Now the below Awk script prints the Student name and Rollno from the above input file.

$cat student.awk
BEGIN {
	RS="\n\n";
	FS="\n";

}
{
	print $1,$2;
}

$ awk -f student.awk  student.txt
Jones 2143
Gondrol 2321
RinRao 2122
Edwin 2537
Dayan 2415

In the script student.awk, it reads each student detail as a single record,because awk RS has been assigned to double new line character and each line in a record is a field, since FS is newline character.

4. Awk ORS Example: Output Record Separator Variable

Awk ORS is an Output equivalent of RS. Each record in the output will be printed with this delimiter. Following is an awk ORS example:

$  awk 'BEGIN{ORS="=";} {print;}' student-marks
Jones 2143 78 84 77=Gondrol 2321 56 58 45=RinRao 2122 38 37 65=Edwin 2537 78 67 45=Dayan 2415 30 47 20=

In the above script,each records in the file student-marks file is delimited by the character “=”.

5. Awk NR Example: Number of Records Variable

Awk NR gives you the total number of records being processed or line number. In the following awk NR example, NR variable has line number, in the END section awk NR tells you the total number of records in a file.

$ awk '{print "Processing Record - ",NR;}END {print NR, "Students Records are processed";}' student-marks
Processing Record -  1
Processing Record -  2
Processing Record -  3
Processing Record -  4
Processing Record -  5
5 Students Records are processed

6. Awk NF Example: Number of Fields in a record

Awk NF gives you the total number of fields in a record. Awk NF will be very useful for validating whether all the fields are exist in a record.

Let us take in the student-marks file, Test3 score is missing for to students as shown below.

$cat student-marks
Jones 2143 78 84 77
Gondrol 2321 56 58 45
RinRao 2122 38 37
Edwin 2537 78 67 45
Dayan 2415 30 47

The following Awk script, prints Record(line) number, and number of fields in that record. So It will be very simple to find out that Test3 score is missing.

$ awk '{print NR,"->",NF}' student-marks
1 -> 5
2 -> 5
3 -> 4
4 -> 5
5 -> 4

7. Awk FILENAME Example: Name of the current input file

FILENAME variable gives the name of the file being read. Awk can accept number of input files to process.

$ awk '{print FILENAME}' student-marks
student-marks
student-marks
student-marks
student-marks
student-marks

In the above example, it prints the FILENAME i.e student-marks for each record of the input file.

8. Awk FNR Example: Number of Records relative to the current input file

When awk reads from the multiple input file, awk NR variable will give the total number of records relative to all the input file. Awk FNR will give you number of records for each input file.

$ awk '{print FILENAME, FNR;}' student-marks bookdetails
student-marks 1
student-marks 2
student-marks 3
student-marks 4
student-marks 5
bookdetails 1
bookdetails 2
bookdetails 3
bookdetails 4
bookdetails 5

In the above example, instead of awk FNR, if you use awk NR, for the file bookdetails the you will get from 6 to 10 for each record.
